Product Code: 513997MPN: GTNW/MULTITRACK
Wrekin White Non-Woven Geotextile Roll (4.5m x 100m)
Quantity
Total Price: £0.00
Ex.VAT
Product Code: 513997MPN: GTNW/MULTITRACK
Wrekin White Non-Woven Geotextile Roll (4.5m x 100m)
Quantity
Total Price: £0.00
Ex.VAT
Non Woven Geotextile range are high quality polypropylene mechanically bonded (needle punched) geotextiles. These mechanically bonded materials are particularly robust with respect to potential installation damage as the combination of tensile strength and extensibility allows the material to flex and accommodate stress and strain whilst inhibiting puncture. These materials have CBR puncture resistance ranging from approximately 1400N to 3600N.
| Third party certified | CE UKCA | |
| Tensile strength (MD) | EN ISO 10319 | 8kN/m |
| Tensile strength (CMD) | EN ISO 10319 | 8kN/m |
| Elongation at max load (MD) | EN ISO 10319 | 45% |
| Elongation at max load (CMD) | EN ISO 10319 | 55% |
| Dynamic perforation resistance | EN ISO 13433 | 34mm |
| CBR puncture resistance | EN ISO 12236 | 1500N |
| Dynamic cone drop | EN ISO 13433 | 34mm |
| Water permeability | EN ISO 11058 | 110L/m.s |
| Characteristic opening size | EN ISO 12956 | 120m |
| Thickness under 2kPa | EN ISO 9863-1 | 1mm |
| Weight | EN ISO 9864 | 100g/m |
| Roll width | 4.5m | |
| Roll length | 100m | |
| Roll diameter | 29cm |
